2005

16.75in Bore Cantilever Skidding Cylinders (Total Pushing Capacity: 1322 KIPS@3,000Psi) for Mobile Offshore Jack-Up Drilling Rig.



Hydraulic system for 2-off 25Ton Pulling Winch with constant tension feature for Offshore application.





2006

16.7in Bore Cantilever Skidding Cylinders (Total Pushing Capacity: 1322 KIPS@3,000Psi) for Mobile Offshore Jack-Up Drilling Rig.



400 tons Winch hydraulic system for testing on hydraulic deck machinery onboard BP Greater Plutonio (FPSO).



Winch hydraulic systems with constant tension control feature for offshore application. Pulling capacity range is from 70Mton to 150 Mton.





2007

Winch hydraulic systems with constant tension control feature for offshore application.



Piping installation on 2 x 100 t/h Boiler Module for FPSO Cidade De Sao Mateuso.



Heave-in Compensator hydraulic Power Pack systems for Offshore Suction Pile lunching installation.





2008

Piping installation 2 x 100 t/h Boiler Module for 2 x 90 t/h Boiler Module for FDPSO Azurite and 2 x 100 t/h Boiler Module for FPSO Ningaloo Vision.



Trouble-shoots Hydraulic System for Mobile Offshore Jack-Up Drilling Rig’s Skidding Hydraulic Power Pack .



Winch hydraulic systems complete with remote and local control panel  for operating 4 x 100ton Double Drum Water Fall Winch.



Total pushing capacity of 450Ton Cylinders for Chain Jack and hydraulic system design.





2009

Piping/hose installation complete with oil flushing, oil cleanliness according to NAS 1638 Standard Code 8, pressure and FAT testing on Hose Storage Reel and Hawser Reel for FPSO Dynamic Producer.



Piping/hose installation complete with mineral oil flushing, oil cleanliness according to NAS 1638 Standard Code 8, pressure and FAT testing on Hose Storage Reel, Hawser Reel Spooling carriage and 2 Reel Loading Station for FPSO Peregrino .



14.5in Bore Cantilever Skidding Cylinders (Total Pushing Capacity: 990 KIPS@3,000PSI working pressure) for Mobile Offshore Jack-Up Drilling Rig.



Refurbished Pull Type Conductor Tensioner Cylinders (Total Pulling Capacity: 200Mton@2,720PSI working pressure) for Mobile Offshore Jack-Up Drilling Rig.



Hub Spooler and Track Tensioner hydraulic systems complete with constant tension remotely control feature and provide hydraulic personnel on operating the Hub Spooler and Track Tensioner equipment for offshore Riser installation for PM3 CAA Field Development Project at Bunga Orkid Oil Field.



Modified the hydraulic systems design to increase the capacity of Hub Spooler with Track Tensioner operation and provide hydraulic personnel on operating the Hub Spooler and Track Tensioner equipment for offshore Riser installation For JDA B-17 Field Development Project.



2010 to 2011

One unit Hydraulic Power Pack to actuate 7-off 800mm bore single acting hydraulic cylinder (Maximum Total Compression: 21000Mton@585bar working pressure) for 183MN Mega Test Press.



Winch Main and Local Control Panel for operating 8 Point Mooring Winch for J626-120m Accommodation Crane Barge.



2012

500 KIPS Load Testing Jib For NAGA1 DSC Cylinder



2013

4-off 1000Mton & 4-off 800Mton ROV Hydraulic Release Shackle Control System

1-off 200Mton ROV Hydraulic Release Shackle Control System
